In HVACR (Heating, Ventilation, Air Conditioning, and Refrigeration) systems, maintaining a stable room temperature is crucial for comfort and efficiency. One effective way to achieve this is by using a concept known as a “deadband.” A deadband helps prevent frequent temperature fluctuations by setting a range around the desired temperature where no heating or cooling action is taken.
A deadband is a temperature range around a set point where the HVAC system does not activate heating or cooling. For instance, if the desired room temperature is 21 degrees Celsius, a deadband of plus or minus one degree means the heating will turn on when the temperature drops below 20 degrees Celsius and turn off when it rises above 22 degrees Celsius. This approach helps maintain an average temperature of 21 degrees Celsius.
The ideal deadband can vary based on several factors, including the specific environment and system characteristics. While computer modeling can assist in determining these values, they are often fine-tuned through trial and error. Small adjustments are made until the optimal balance between comfort and system efficiency is achieved.
Traditional on-and-off control methods can struggle to maintain a consistent temperature. Instead, modulating valves can be used to adjust the thermal output within the deadband. In a basic heating system, a gas boiler might initially run at full power to heat water. However, a motorized valve can then reduce the gas supply, lowering the heat output without turning off the boiler. This ensures that the heat output matches the heat loss from the room, maintaining the set temperature within the deadband.
Most HVAC systems have a single heating or cooling source connected to multiple radiators or fan coil units, often located in different rooms. To control the output of these individual units, a thermostatic radiator valve can be used. This valve contains a chamber filled with a wax liquid or gas that expands and contracts with temperature changes, adjusting the valve position accordingly. As the room gets hotter, the valve closes more, and as it gets colder, the valve opens more, ensuring the radiator’s heat output matches the room’s demand.
Alternatively, a motorized valve controlled by a room thermostat can adjust the flow rate of hot or cold water into a radiator or fan coil unit. This method allows for precise thermal output adjustments to meet the room’s needs. However, if a fixed-speed pump supplies multiple units, closing one valve can increase pressure in the pipes, inadvertently increasing the flow rate through other valves. This can lead to constant adjustments and increased wear on the system.
To address this issue, a pressure sensor and a variable speed pump can be installed. As valves open and close, the pump adjusts its speed to maintain constant pressure and flow rate through the radiators, regardless of other valves’ positions. This setup ensures consistent temperature control and reduces system wear.
For more detailed insights into how variable speed drives and pumps work, check out our previous videos. Continue exploring HVAC engineering by watching the recommended videos on screen now. Stay connected with us on social media and visit engineeringmindset.com for more resources.
Engage with an online simulation tool that allows you to adjust the deadband settings in a virtual HVACR system. Observe how different deadband ranges affect temperature stability and system efficiency. Reflect on how these adjustments can be applied in real-world scenarios.
Analyze a case study of an HVACR system in a commercial building. Identify the deadband settings used and evaluate their effectiveness in maintaining comfort and efficiency. Discuss your findings with peers and propose any potential improvements.
Work in groups to design an HVACR system for a hypothetical building. Determine the appropriate deadband settings and justify your choices based on environmental factors and system characteristics. Present your design to the class, highlighting how it optimizes comfort and efficiency.
Participate in a lab session where you can experiment with thermostatic radiator valves. Observe how the valves respond to temperature changes and adjust the heat output. Document your observations and discuss how these valves contribute to maintaining the deadband.
Conduct research on the role of variable speed pumps in HVACR systems. Prepare a presentation that explains how these pumps help maintain consistent pressure and flow rates, enhancing system efficiency. Share your insights with classmates and engage in a Q&A session.
Here’s a sanitized version of the provided YouTube transcript:
—
To alleviate swings in temperature, we set a deadband condition, typically plus or minus one degree Celsius from the required temperature. For example, if we want a room temperature of 21 degrees Celsius with a deadband of plus or minus one degree, the heating will turn on when the room temperature falls below 20 degrees Celsius and will switch off when it is above 22 degrees Celsius. This gives us an average temperature of 21 degrees Celsius.
The deadband values depend on many factors and can be modeled on a computer, but generally, they are found through trial and error with small incremental changes to find the optimal point where the room is comfortable and the system operates efficiently.
On-and-off control makes it difficult to maintain a desired temperature. Instead, we can use special valves to modulate the thermal output, keeping the temperature within a certain deadband. In a simple heating system, when the gas boiler turns on, it will run at full power to heat the water, but then it reduces the gas supply by using a motorized valve. This reduces the heat output of the boiler instead of turning it off. The water temperature set point is kept in the deadband, so the heat output is equal to the heat leaking out of the room.
Most systems have a single heating or cooling source with multiple radiators or fan coil units connected to this. These are usually in different rooms, so we need to control the output of the individual units. The simplest method to achieve this is the thermostatic radiator valve. This valve is found on heated water systems and uses a chamber filled with a wax liquid or gas that expands and contracts as the room temperature changes, controlling the valve position. The hotter it gets, the further it closes the valve; the colder it gets, the more it opens the valve. Thus, the heat output of the radiator matches the demand of the room.
Alternatively, a radiator or fan coil unit could use a motorized valve controlled by a thermostat in the room. This will vary the flow rate of hot or cold water into the unit, adjusting the thermal output to match the demand. However, if a fixed-speed pump supplies multiple units, then as one valve closes, it causes a pressure increase in the pipework, leading to an increased flow rate of water through the other valves. This can be problematic as it may increase the heat output, causing the valves to constantly adjust in an attempt to maintain the correct temperature, which can lead to faster wear and tear.
To overcome this, we could install a pressure sensor and a variable speed pump. As the valves open and close, the pump changes speed to maintain a constant pressure and thus a constant flow rate through the radiators, regardless of when another valve opens or closes.
We have covered how variable speed drives work and how pumps operate in our previous videos. Be sure to check those out; I’ll leave a link in the video description below.
Check out one of the videos on screen now to continue learning HVAC engineering. This is the end of this video. Don’t forget to follow us on Facebook, LinkedIn, Twitter, Instagram, TikTok, and visit engineeringmindset.com.
—
This version maintains the original content’s meaning while ensuring clarity and readability.
Deadband – A range of input values in a control system where no output change occurs, often used to prevent unnecessary oscillations or adjustments. – In the HVAC system, a deadband of 2 degrees Celsius was set to avoid frequent switching between heating and cooling modes.
Temperature – A measure of the average kinetic energy of the particles in a substance, often used as a critical parameter in engineering and physics applications. – The temperature of the reactor must be carefully monitored to ensure the chemical reaction proceeds safely and efficiently.
Efficiency – The ratio of useful output to total input in any system, often expressed as a percentage, indicating how well a system converts energy or resources into desired outcomes. – The efficiency of the new solar panels was measured at 22%, making them one of the most effective options available for renewable energy projects.
Control – The process of managing or regulating the behavior of a system to achieve desired outputs, often through feedback mechanisms. – Engineers designed a sophisticated control system to maintain the stability of the aircraft during turbulent conditions.
Output – The result or product generated by a system, often measured to assess performance or effectiveness. – The output of the power plant was increased by 15% after the installation of more efficient turbines.
System – A set of interconnected components that work together to achieve a specific function or purpose, often analyzed in engineering and physics to optimize performance. – The water distribution system was upgraded to improve reliability and reduce energy consumption.
Valves – Mechanical devices used to control the flow of fluids within a system, crucial for regulating pressure and flow rates in engineering applications. – The maintenance team replaced the faulty valves to ensure the hydraulic system operated smoothly and without leaks.
Heating – The process of raising the temperature of a substance or environment, often achieved through various energy sources and technologies in engineering applications. – The heating system in the laboratory was upgraded to provide more consistent temperatures for sensitive experiments.
Cooling – The process of removing heat from a substance or environment, often necessary to maintain optimal operating conditions in engineering systems. – The cooling system in the data center was enhanced to prevent overheating of critical servers during peak usage times.
Pressure – The force exerted per unit area, often a critical parameter in engineering and physics, affecting the behavior of fluids and gases. – The pressure in the pipeline was carefully monitored to prevent any risk of rupture or leakage.
