In this lesson, Destin from Smarter Every Day explores the physics and engineering behind the Supersonic Baseball Cannon, which successfully propels a baseball beyond the speed of sound, reaching approximately 1,050 mph. Inspired by his childhood fascination with legendary pitcher Nolan Ryan, Destin and his team designed a complex cannon that utilizes pressure differences to minimize air resistance and achieve supersonic speeds. The experiment not only satisfies Destin’s curiosity but also highlights the intersection of creativity, engineering, and scientific principles in pushing the boundaries of what is possible.

World’s Fastest Pitch: Exploring the Supersonic Baseball Cannon

Welcome to an exciting exploration of physics and engineering with Destin from Smarter Every Day. Have you ever wondered what happens when a baseball travels faster than the speed of sound? This intriguing question has fascinated Destin since childhood, and today, we dive into the mechanics behind achieving such incredible speeds with a baseball.

The Inspiration Behind the Experiment

Destin’s curiosity about supersonic baseballs began with a childhood book report on Nolan Ryan, the legendary pitcher who threw the first recorded 100 mph pitch in 1974. This fascination led Destin to explore aerodynamics and the physics of objects moving through the air, eventually becoming part of his professional work as a developmental weapons tester.

The Supersonic Baseball Cannon

Combining his love for aerodynamics, baseball, and air cannons, Destin and his team set out to create a Supersonic Baseball Cannon. The goal was to propel a baseball beyond the speed of sound, which is approximately 767 mph (Mach 1). The challenge involved significant engineering to overcome the baseball’s size and weight compared to a golf ball, which had been used in a previous experiment.

Engineering the Cannon

The team designed a complex system to achieve supersonic speeds. The cannon works by creating a high-pressure environment behind the baseball and a vacuum in front of it. This pressure difference propels the baseball down a 20-foot barrel at incredible speeds. Key components include a sear mechanism to release the baseball and a shock absorber to manage the forces involved.

Overcoming Challenges

One of the main challenges was ensuring minimal air resistance inside the barrel. To address this, the team added extra vacuum volumes to allow any remaining air to escape, reducing drag and maximizing the baseball’s velocity.

The Experiment in Action

After meticulous preparation and testing, the team was ready to fire the cannon. Using nitrogen, which has a higher speed of sound than air, they aimed to achieve supersonic speeds. The setup included a Schlieren system to visualize shockwaves and a high-speed camera to capture the baseball’s motion.

Results and Observations

The experiment was a success, with the baseball reaching speeds of approximately 1,050 mph, or Mach 1.38. The high-speed footage revealed the formation of a Mach cone, confirming the baseball’s supersonic velocity. The team used precise measurements and calculations to verify these results, demonstrating the power of engineering and physics in achieving such feats.

Conclusion

This experiment not only satisfied Destin’s lifelong curiosity but also provided valuable insights into the physics of supersonic motion. By combining creativity, engineering, and scientific principles, the team successfully pushed the boundaries of what a baseball can achieve. This project serves as a testament to the exciting possibilities that arise when curiosity meets innovation.

Whether you’re a baseball enthusiast or a physics aficionado, the Supersonic Baseball Cannon offers a thrilling glimpse into the world of high-speed dynamics and the wonders of scientific exploration.

  1. What aspects of the article about the Supersonic Baseball Cannon did you find most intriguing, and why?
  2. How did Destin’s childhood curiosity about Nolan Ryan’s pitching influence his career and the development of the Supersonic Baseball Cannon?
  3. What engineering challenges did the team face in creating the Supersonic Baseball Cannon, and how did they overcome them?
  4. In what ways did the experiment with the Supersonic Baseball Cannon expand your understanding of physics and aerodynamics?
  5. How do you think the use of nitrogen, with its higher speed of sound, contributed to the success of the experiment?
  6. What insights did you gain about the relationship between creativity and scientific principles from this experiment?
  7. How do you think the visualization techniques, like the Schlieren system, enhanced the understanding of the experiment’s results?
  8. Reflecting on the article, what new questions or curiosities do you have about supersonic motion or other high-speed dynamics?
  1. Design Your Own Supersonic Experiment

    Imagine you are tasked with creating a new experiment to test the limits of supersonic speeds using a different object. Consider the physics principles involved, such as aerodynamics and pressure differences. Present your design to the class, explaining the engineering challenges and how you plan to overcome them.

  2. Analyze High-Speed Footage

    Watch high-speed footage of the Supersonic Baseball Cannon experiment. Identify and explain the formation of the Mach cone and other phenomena observed. Discuss how these observations align with theoretical predictions in physics.

  3. Group Discussion: The Physics of Supersonic Motion

    In groups, discuss the physics concepts that enable a baseball to travel at supersonic speeds. Focus on topics such as shockwaves, air resistance, and the role of pressure. Share your insights with the class and explore how these principles apply to other supersonic objects.

  4. Engineering Challenge: Optimize the Cannon Design

    Work in teams to propose modifications to the Supersonic Baseball Cannon design that could further increase the baseball’s speed. Consider factors like barrel length, pressure systems, and materials. Present your ideas and justify your choices based on engineering principles.

  5. Research Presentation: Historical Context of Supersonic Achievements

    Research the history of supersonic achievements, from the first supersonic flight to modern applications. Create a presentation that highlights key milestones and technological advancements. Discuss how these achievements have influenced current scientific and engineering practices.

Sure! Here’s a sanitized version of the transcript, with any inappropriate language or sensitive content removed:

Hey, it’s me, Destin. Welcome back to Smarter Every Day. You read the title of the video, didn’t you? You know what’s about to happen. Here’s the deal though, I’ve got to explain it to you. This is not just someone trying to make an internet video. This is me trying to answer a question that I’ve wanted to know my entire life: What happens when a baseball goes past the speed of sound?

There are very specific reasons why I want to know this. This is a Smarter Every Day baseball, by the way—more about that later. When I was a kid, I did a book report on “Nolan Ryan Strikeout King.” I learned that in 1974, Nolan Ryan, while playing for the Angels, threw the first recorded baseball past a hundred miles per hour. After learning about that pitch, every time I stepped onto the field, I thought about the ballistics of throwing a baseball through the air.

As I went forward into school, I started learning about aerodynamics and realized there was math associated with all this stuff. I fell in love with the mechanics of how things fly through the air, to the point where, as part of my job as a developmental weapons tester, I developed a pretty intimate relationship with air cannons.

If you were to draw a Venn diagram of everything I love— aerodynamics, baseball, air cannons—right in the center of all that is the Supersonic Baseball Cannon. So today’s video had to happen for me. I have to know what happens when a baseball goes past the speed of sound. Like, does the cover rip off because of the shockwave? What exactly happens when this thing goes Mach one? Let’s go learn and get Smarter Every Day.

In an earlier episode of Smarter Every Day, we made a golf ball air cannon. We put a golf ball in there, pressurized one side, and put tape over the end. We used a vacuum pump to pull a vacuum inside of a barrel. When we released that pressure, the golf ball accelerated down the barrel, ruptured the tape, and exited at an incredible velocity.

What we want to do here is basically the same thing, only at a much larger scale. The baseball is 1.6 times larger than the golf ball and three times as heavy. Mach One is 767 miles an hour. So in order to do this, we have to do some serious engineering. I got some buddies to help me out, and we started brainstorming.

You’ll remember David from the vortex collision device, Jeremy Fielding from the mad batter, and Trent from the lawn tool videos. (David) If you got holes in there, it’s got to go around corners. (Destin) Okay, so imagine this… Imagine. So right now we’ve got pipe and then we’re pulling the plug out, and then all the air rushes in the end there, right? Yeah. What if we have the pipe all the way inside the tank? (David) This really is just a cone to make sure… (Destin) Guide it in there… (David) …to reengage the barrel every time. And it also retains the seal.

We may be able to get supersonic velocity with air just because of the vacuum here and because of the Venturi. (Jeremy) As soon as I start modeling, I’m going to have a bunch of questions. Because at that point, I’m putting screws there. (David) It’s going to be long. (Trent) Just get a longer trailer, man… (Destin) Just get a longer trailer… We need to talk about that.

So I’ve been successful in uniting you both against me. So it sounds like we’re ready to go. (Everyone laughing) (David) Now that we’ve decided how we’re going to do it, we’ll tell Destin what we came up with. Okay. I want to show you how this thing works because it’s awesome. This is the solid works model. We’re going to cut this thing in half and zoom in right here to show you what it looks like on the inside.

The whole idea here is we want that baseball to go really fast. To do that, we needed a whole lot of air on one side and not a lot of air on the other. That difference in pressure will make it go. This seal right here is how we create that difference in pressure. We can pressurize the tank on the left here, and then we pull a vacuum on the barrel on the right when we’re ready to fire.

If we pull that rod back, it’ll break the seal, dumping all that air behind the baseball and off she goes. Pressurizing this tank is a little bit harder than it might seem because you have several different places air could leak out. We have a gasket here, here, here, and a dynamic seal on the rod back here. So when we pressurize that tank, it’s going to try to push that rod out the back of the tank, just like a syringe… which sounds like a bad thing, but it’s actually good because we’re going to use that force to try to pop the cork on the baseball even faster.

To do this, we designed this sear mechanism at the back of the tank. We push the rod into place really hard. Then we compress that front gasket, making a seal behind the baseball. We then click up this little thing and it holds everything together. If we get all the alignment right, since it’s one long rod that keeps the gasket in the front sealed until the moment we want to release it, we then pressurize everything in the tank.

Then we release that sear and it’ll dump all the air into the baseball, so it goes really fast. The problem is now the rod is free and it starts to move back very fast and it’s so heavy. It could break stuff. So to fix that, we have this shock absorber in the back that we can tune with a valve to try to slow down and stop the rod.

Let’s go forward and look at some of the cool things we did to the vacuum side on the barrel. With the golf ball cannon, when we looked at the slow-mo, I observed that as the ball got closer to the end of the barrel, it started to inflate the tape. That told me that there was still air inside the barrel, meaning we were losing some of the velocity in the barrel due to drag.

In an effort to get rid of any extra air in this 20-foot long barrel, we had two extra vacuum volumes on the front. We’ve got this big cylinder up front here. And then we have this big red box beam underneath the barrel. The idea is, as the ball goes down that 20-foot long barrel, if there’s any extra air in there, it has a place to go.

I don’t really know if this part is going to work. I honestly just kind of made it up, but it makes sense. You want to suck the ball to the end of the barrel and you want to get rid of the air that’s in the way. So you’ve got what I call “extra vacuum ullage.” Anyway, it doesn’t matter.

[BUILD MONTAGE]

Since the dawn of blacksmithing, the relationship between welders and engineers has been contentious, wouldn’t you say? [Laughter]

Okay. Moment of truth. We’re going to pressurize this thing. The question here is… we’ve got that rod running all the way through. Does the pressure seal off right here where that plug is? And also do our seals back here work? What do you think? 300 PSI? Yeah, that sounds like a good test.

IT IS TIME. The moment we’ve been waiting for. Oh my goodness. Look at that. Oh dude. (Jeremy) Oh it’s moving now! (Destin) Oh dude. What have we done? Going Up! (Destin) Oh, dude… (Jeremy) This is insane man… This is insane. (Destin) Oh, golly guys. Okay, here we go. Mark 1 Supersonic Baseball Cannon. Take One. Baseball’s loaded. Goggle up, guys. Science is about to happen. Here we go.

It appears to be holding all right, so first shot 300 PSI. (Jeremy) It’s definitely quiet. I don’t hear anything up here. (Destin) No leaking? You guys ready? Three, two, one. [SUPER LOUD BLAST] [excited noises] OH MY GOSH. Oh my goodness. I think we need to paint this thing and we need to get out in a more scientific environment and probably get the high-speed camera out and see what’s going on. But this is incredible.

Okay. We have the thing built. We have all of the baseballs ordered. That is a ton of baseballs. They’re really cool, by the way. They have a Smarter Every Day logo on one side and the Rocket City Trash Pandas on the other. More about that later. There’s a way you can actually get one of these baseballs.

Anyway, now that we built it, we have to control it. This is what we want to do. We want to make a controller for the whole thing. We need gauges all in one location so we can monitor the chamber pressure. We also need to know the vacuum pressure in the barrel itself. We need to have all of this information in one location so that when it comes time to hit the big red button and send this baseball at supersonic velocities, we’ll have it all right there in one spot.

So we painted the cannon. We did some low-pressure testing, which I’m sure the neighbors blamed on Redstone Arsenal nearby. And I dubbed it “The Mark One Supersonic Baseball Cannon.” Today is the day we’re going to shoot the first baseball in a relatively controlled environment.

So the goal for today is just to see if we can get above the speed of sound in one shot with nitrogen. I doubt we can. This is Trent setting up the Schlieren here. We’ve got this mirror and we’re just going to see if we can see the shockwave go across and the shadow graph of the baseball.

We’re shooting with nitrogen; the reason we’re shooting with nitrogen is the molecular weight is around 28. Jeremy’s excited. Are you excited? – Definitely excited. – We are excited. We’re gonna be shooting with nitrogen because the speed of sound of nitrogen is higher than the speed of sound in air. Interestingly, I learned this: The speed of sound in humid air is higher than dry air.

Anyway, what I’m going to do is… because we’re going to be pressurizing that thing really high, we’re going to be setting this thing up as a place to get behind when we are getting ready to shoot. I’ve got to focus on what I’m doing. Can you spin this at a 45 the other way? Uh, orthogonal to the gun coming down. If that thing blows up, we don’t want anyone back here.

Alright, so let’s get ready for the shot. We are using a single light source for our schlieren setup. So, that’s a fiber optic light. The fiber optic light goes and bounces off the mirror, comes back. We’re cutting the light with that razor right there. It’s hard to see because I was in the way. Trent, do you mind getting the matches? (Trent) Yep! I have it.

But what happens is, if you look here at our schlieren setup, Trent’s gonna light the matches right there. You should see a double. Yeah. Hold it up just a little bit. There you go. See the double match? That’s because there’s a shadow going across the match and then coming back through the match.

So let’s talk through what we’re about to see. There’s some stuff going on here. So back when Nolan Ryan used to pitch, they would measure the speed of the pitch at the plate. Now they measure the speed of the pitch at the hand. This is important because I don’t think what we’re about to do is going to be supersonic.

This is day one; we’re ringing everything out. I’m going to come out here and fiddle in the field for however many weeks it takes to get the exact shot I’m looking for, which is a shockwave over the baseball. So what I think is going to happen is we’ve got the baseball as it exits here. I think it’s going to exit supersonic just because of the speed of sound in nitrogen.

But the shockwave is going to come out, and the baseball, at some point, is going to outrun… It’s going to be transonic in this region. My hypothesis is that the baseball will be subsonic when it passes the mirror and we won’t get the supersonic shot today. It might be supersonic, but we won’t see it.

So, this thing, the math says we can be rated up to a thousand PSI. We’re going to go to 750 PSI. We’ve got a big thick, real big thick shield over there. Let’s go look at it real quick. So here you go: two, one-inch thick sheets of steel. That is a massive target. Let’s get a baseball.

[exhaling excitedly] It’s time. It is time. Okay. We’re about to go through the safety checklist, which is right here. This is what the control panel looks like. We tried to make it as straightforward as possible. We’re going to add gas here. We’re gonna do the first shot at 750 PSI, which is the highest pressure we’ve ever pressurized this thing to.

If you know anything about pressure vessels, we’re going to be behind this steel. Right? (Jeremy) Absolutely! So, here we go. Ready for loading procedures. – Ramrod. – There we go. Is your heart beating fast? It is. You’re excited too. It doesn’t feel right to be this excited about a thing.

[tape cutting] (Jeremy) Confirm all-clear of the trailer. CLEAR. (Jeremy) Switch tank to vent ready. – Oh man. You’re ready. – I’m ready. Okay. (Jeremy) Okay. So the tank is capable of holding pressure now. So we’re pulling the vacuum now; my heart’s not beating quite as fast. Is yours? (Jeremy) It’s had a chance to calm down.

Okay. All right. [more heavy breathing] So an absolute vacuum is negative 14.7 PSI. If we can get somewhere below 13, we’re good. About to pressurize here, by adding gas. Alright. Tank is pressurizing. Nobody get outside the steel right now. That is a lot of volume. So we’re gonna be holding this for quite a while.

This is tickling all of the brain parts that need to be tickled. (Jeremy) Yes. (Destin) We got baseball. We’ve got… we’ve got ideal gas law. We’ve got aerodynamics. We have mechanics. We have mechanical design. I get to push a button and loud things happen. (Jeremy) You get to push a button underneath a red cover switch. [laughing]

Alright, here we go. 180 PSI. We’re at minus 13.9 on the vacuum. There will be a significant sonic boom. (Trent) I’m scared. I’m a little tingly. We’re at… not quite 300 PSI. Dude, we have a really good vacuum right now. 540 PSI. [Urgently] We’re losing our vacuum. Hey, we’re losing our vacuum. Do you want to shoot? Here we go. Get ready? Ready? Three, two, one.

[LOUD BLAST] (Destin) WHAT ON EARTH. Where did it go? (Jeremy) That ball disintegrated! (Destin) No it didn’t? (Jeremy) I think it hit the…. (Destin) It did hit the back. [Laughing] Get the, get the… (Jeremy) Hold on, the tank is safe! Tank is safe. [grown men giggling] (Jeremy) It shredded it man! Oh wait, you can see the seams! (Destin) Fantastic!

Okay… So at some point we’re going to get that high-speed. (Destin narrating) OK, here we go, moment of truth. I got to admit, when I first saw this, it was genuinely hard to believe my eyes. (Destin) Okay yeah so… [screams of disbelief] (Jeremy) Oh man. Dude. What have we… What have we done? Look at it. It’s beautiful.

(Jeremy) Can we just walk over and put a ruler in front of the mirror now? (Destin) That’s supersonic. (Jeremy) …and then we’ll know how much that transient space is? (Destin) You can tell it’s supersonic by the angle. Like, it has a Mach cone! (Jeremy) There’s another… (Destin) What is that? Is it closing behind it? (Jeremy) You’ve got something funky going on. Wow.

(Destin) I have no idea what we’ve done. We need to measure. We need to figure out that velocity. So you have something we can calibrate? (Trent) Yeah, absolutely. (Destin) Point Zero One Four… Now this is rough. Okay, that’s it. Now… 1,050 miles an hour… 1,050 miles an hour. Where’s my phone? Mach 1.38.

Okay. (Laughs) I’m legitimately having problems functioning correctly. It just seems too fast. Like this is just imagery and math. That’s all this is. We’re going to make sure that we actually did go supersonic because the shockwave was detached from the nose of the baseballs on schlieren.

So we’ve got a stob here and a stob here. They’re 12 feet apart. We’ve got the camera right there. So as the baseball goes across, not only can we get velocity this time, we’ve got a really good pixel calibration and we’ll be able to get the drag coefficient and the baseball. 530 PSI… about minus four on the vacuum.

Okay, here we go. Five, four, three, two, one. [Explosive sound] (Destin voiceover) Okay. The indisputable two stick method. Velocity is equal to distance divided by time. The time to the first stick is 29 milliseconds. And remember, this is happening fast. We’re recording at 28,500 frames per second. The time to the second stick is 36.8 milliseconds.

Subtract those two and divide, that gives us 1,538 feet per second, which is basically 1050 miles per hour. Adjust for altitude and temperature. And… Yeah. Hey, it’s supersonic. That was Mach 1.35. I mean, that’s just measured straight up with poles.

Okay… we have a supersonic baseball cannon. It is verified. Ready? Three, two, one, fire. [Explosive sound] (Destin Narrating) We’ve all heard the expression “knocking the cover off the ball,” but the ability of a baseball to be destroyed by literally ripping itself apart with kinetic energy is

PhysicsThe branch of science concerned with the nature and properties of matter and energy. – In our physics class, we explored the fundamental principles that govern the behavior of the universe.

EngineeringThe application of scientific and mathematical principles to design and build structures, machines, and systems. – The engineering team developed a new bridge design that improved load distribution and reduced material costs.

AerodynamicsThe study of the properties of moving air and the interaction between the air and solid bodies moving through it. – The aerodynamics of the new aircraft were optimized to reduce fuel consumption and increase speed.

BaseballA sport that involves hitting a ball with a bat and running bases, often used in physics to study projectile motion and collision. – The physics professor used the trajectory of a baseball to explain the concepts of parabolic motion and air resistance.

SupersonicRelating to speeds greater than the speed of sound in air. – The development of supersonic jets has revolutionized air travel by significantly reducing flight times.

VelocityThe speed of something in a given direction. – The velocity of the car was calculated using the change in its position over time during the physics experiment.

DragThe resistance force caused by the motion of a body through a fluid, such as air or water. – Engineers must consider drag when designing vehicles to ensure they are both efficient and fast.

PressureThe force exerted per unit area on the surface of an object. – The pressure inside the container was measured to ensure it could withstand the conditions of the experiment.

VacuumA space entirely devoid of matter, where the pressure is significantly lower than atmospheric pressure. – The experiment was conducted in a vacuum to eliminate air resistance and observe the true effects of gravity.

InnovationThe process of translating an idea or invention into a good or service that creates value or for which customers will pay. – The engineering department is known for its innovation in developing sustainable energy solutions.
